Wondery Servo Aluminum Radiator Crimping Machine 1050mm Core Height

Name: Wondery Servo Aluminum Radiator Crimping Machine 1050mm Core Height
Brand: Wuxi Wondery Industry Equipment Co., Ltd
Price: 25.00 USD
Availability: InStock

الاسم التجاري:	WONDERY
مو:	1
السعر:	$23,000-27,000

معلومات تفصيلية

وصف المنتج

معلومات تفصيلية

مكان المنشأ:

جيانغسو

وزن:

3200 كجم

ارتفاع الأساس:

1050mm

العرض الأساسي:

1000mm

سمك الحد الأقصى:

120mm

أسنان مجعد:

100 قطعة

مزود الطاقة:

AC-220V ؛ 50 هرتز

أبعاد:

2400 × 2200 × 2200 مم

نظام التحكم:

PLC وشاشة تعمل باللمس

تحويلة تقريبية:

أومرون ، اليابان

المرشد الخطى:

TBI ، تايوان

مكونات تعمل بالهواء المضغوط:

Airtac ، تايوان

PLC وHMI:

دلتا ، تايوان

محرك المؤازرة:

دلتا ، تايوان

موصل:

شنايدر ، الصين

مبدأ العمل:

الضغط والضغط والكتابة

إبراز:

aluminum radiator crimping machine,servo radiator fin machine,1050mm core height crimper

servo radiator fin machine

1050mm core height crimper

وصف المنتج

Servo Type Aluminum Radiator Plastic Tank Crimping Machine

High Efficiency Crimping Solution

The aluminum radiator plastic tank crimping clinching machine is designed for crimping the teeth of header plates and securely locking plastic tanks to the core body. This creates a sealed space between the crimped plastic tank, sealing gasket, and header plate. Our servo-controlled machine handles products of various specifications with precision and efficiency.

Key Features

PLC controlled with HMI screen for easy operation
Servo and pneumatic power system for automatic 4-side clinching
Automatic dodging function to prevent collision with water pipes
Programmable for different radiator specifications
Quick-change clinching tools for different tank sizes
Comprehensive safety features including alarm lamp and photoelectric sensors

Technical Specifications

Specification	Value
Max core height	1050mm (customizable)
Max core width	1000mm (customizable)
Maximum thickness	120mm (customizable)
Max crimped teeth quantity	100 pieces
Power supply	AC-220V, 50Hz
Dimensions	2400×2200×2200mm
Weight	Approx. 3200kg

Premium Components

Proximity switch: Omron, Japan

Linear guide and ball screw: TBI, Taiwan

Pneumatic components: AIRTAC, Taiwan

PLC and HMI: Delta, Taiwan

Servo motor & driver: Delta, Taiwan

Electrical components: Schneider, China

Operation Highlights

Precise crimping program setup via touch screen interface
Real-time working status monitoring
Separate long-header and short-header crimping devices
Advanced movement capabilities including dodge and step-forward moves

About Wuxi Wondery Industry Equipment Co., Ltd.

We are a professional supplier of industrial machines serving various industries including automotive, HVAC, and power generation. Established in 2008, we specialize in radiator manufacturing equipment and offer comprehensive services including technical consultation, installation, training, and maintenance. Our machines have been exported worldwide to countries including USA, Australia, Mexico, India, and many others.

Frequently Asked Questions

What is the power supply requirement?

The power supply can be adjusted to match your local requirements through a transformer or direct voltage matching.

What information is needed for quotation?

Please provide technical requirements, drawings, pictures, industrial voltage, and planned output.

What are the payment terms?

40% down payment, 60% before delivery (T/T transfer).

What is the delivery time?

30-60 days after receipt of down payment.
